2
W H A T ’S O N T H E M O D U L E ?
Edge connector, P3 ConnectCore 9C and Wi-9C
Dimm
Pin
Signal
BootStrap
(BS) /
System /
Other
UART
SPI
I2C
USB
LCD
IEEE
1284
PWM /
Timer
/ IRQ
Notes
24
GPIO[71]
iic_sda
GPIO[71] : Output drive 8mA
iic_sda: Primary on GPIO[35]
15K (cc9c) or 2k4 (wi-0c) pull-up on
module Wi-9C uses iic_sda @ addr
A2/A3 on module.
25
26
ADDRESS_4
GPIO[70]
Address bus
iic_scl
CSO parallel port
GPIO[70]: Output drive 8mA
iic_scl: Primary on GPIO[34]
15K (cc9c) or 2k4 (wi-0c) pull-up on
module Wi-9C uses iic_sda @ addr
A2/A3 on module.
27
28
ADDRESS_5
GPIO[69]
Address bus
IRQ1
CSO parallel port
GPIO[69]: Output drive 8mA
IRQ1: Primary on GPIO[07]
Add 10-15K pullup if not used
29
30
GND
GND
Common GND return
Common GND return
31
GPIO[27]
DCD_D
ENBL_D
CLD3
TIMER4
32
No connect
33
GPIO[26]
RI_D
CLK_D
CLD2
TIMER3
34
GPIO[67]
Reserved: CR1- Green user
LED+MFGO
Output drive 8mA
35
36
GPIO[25]
GPIO[66]
DSR_D
CLD1
Reserved: CR2- Yellow user LED+
F/F resed on module.
Output drive 8mA
37
GPIO[24]
BS:
DTR_D
CLD0
CS1_MSB
38
39
40
GPIO[23]
GND
GND
DCD_C
ENBL_C
LINE_END
Common GND return
Common GND return
41
GPIO[47]
CTS_D
RXD-
PINIT#
RXD-: Only used for unidirectional
PHY
42
GPIO[22]
RI_C
CLK_C
CLAC
43
GPIO[46]
RTS_D
RXD+
PAFD#
RXD+: Only used for unidirectional
PHY
44
GPIO[21]
DSR_C
CLFP
VSYNC
45
GPIO[45]
RXD_D
DIN_D
RCV
PSTB#
46
GPIO[20]
BS: CS1_LSB
DTR_C
CLCP/LDC
GPIO[20]: Output drive 8mA
CLKO
47
GPIO[44]
BS: Endian
TXD_D
DOUT_D
OE
PSELO
Pull down for
Big Endian
48
GPIO[43]
CTS_C
DATA-
PDIR
Add 10-15K pullup if not used
20
ConnectCore 9C/Wi -9C Hardware Reference, Rev D 05/2010
